APC ProtectNet standalone surge protector for analog/DSL phone lines (2 lines, 4 wires)

PTEL2

APC ProtectNet standalone surge protector for analog/DSL phone lines (2 lines, 4 wires)

Includes: User Manual

Liên hệ

Giao hàng toàn quốc

Thanh toán khi nhận hàng

Hoàn 100% tiền nếu hàng không đúng như web

Input

  • Input Connections
    --
  • Number of Power Cords
    1

Surge Protection and Filtering

  • Data Line Protection
    RJ-45 Modem/Fax/DSL protection (four wire dual line)
  • Data Lines Protected
    (multi-line only)
    3-6 RJ45
  • ts_nm_surge_response
    1ns
  • Peak Current Common Mode
    0.15kAmps
  • Peak Current Normal Mode
    0.2kAmps

Physical

  • Maximum Height
    103mm , 10.3CM
  • Maximum Width
    47mm , 4.7CM
  • Maximum Depth
    28mm , 2.8CM
  • Net Weight
    0.06KG
  • Shipping weight
    0.14KG
  • Shipping Height
    104mm , 10.4CM
  • Shipping Width
    90mm , 9.0CM
  • Shipping Depth
    29mm , 2.9CM
  • Color
    Beige
  • Master Carton Units
    144.0
  • Units per Pallet
    750.0
  • SCC Codes
    10731304000430

Environmental

  • Operating Temperature
    -15 - 45 °C
  • Operating Relative Humidity
    0 - 95 %
  • Storage Temperature
    -15 - 45 °C
  • Storage Relative Humidity
    0 - 95 %

Conformance

  • Approvals
    UL 497A, UL Listed
  • Standard warranty
    10 years repair or replace

Sustainable Offer Status

  • RoHS
    Compliant
  • Other Environmental Compliance
    China RoHS
